DESCRIPTION

Basic Info.

Model NO.	JRLDR395
Installation	Vertical
Centrifuge Type	Disc Centrifuge
Distillation Equipment Type	Separation Equipment
Extraction Tower Type	Separation Equipment
Pressure	Low Pressure
Condition	New
Bearing	SKF
After-Sales Service Provied	Engineers Available to Service Machinery Overseas
Control Type	PLC Control Box
Certification	ISO/Eac
Application	Industrail/Chemical/Food/Pharmac
Separation Phase	Two/Three Phase
Impurity	Less Than 1ppm
Transport Package	Wooden Case
Specification	depend on model
Trademark	FIVEMEN
Origin	Jiangsu, China
HS Code	8421192000
Production Capacity	50-100L/H

Product Description

Product Description
Introduction:

Latex series disc separator is good equipment for producing latex. It is mainly used for natural rubber slurry concentration and clarification, makes rubber slurry separate concentrated latex and clear skim latex, and eliminates the solid impurity of whey liquid. Separator's design, manufacture and checking and acceptance comply with national standard GB10897 and GB10898..

l.

Moled and Parameters:

Model	JRLDR395
Drum diameter mm	395
Capacity L/h	400-650
Drum rotating speed rpm	7069
Separation factor	11032
Motor power KW	11
Work state	Open type
Dimension mm	1340*740*1670
Weight kg	≈900

Disc centrifuge working principle
FIVEMEN Disc centrifuge is a centrifugal separator which can separate solid matter from two kinds of different density liquids on a continuous basis and also to separate two liquids simultaneously. By reducing process cycle time and labor requirements, these separators offer high cost efficiency in liquid clarification and reclamation, solid-liquid separation and its classification, recovery and thickening of solids and in other such processes.

Main Features

The natural latex is from rubber tree, milk white, solid content is 30%~40%, and the average diameter of solid is 1.06um. The fresh natural latex contain latex 27%~41.3%(m/m), water 44%~70%, protein 0.2-4.5%, natural resin 2%~5% , saccharides 0.36%~4.2% and ash 0.4% . To facilitate transportation and processing, natural rubber latex should be concentrated to the solid content of 60% by adopting the method of centrifugal centrifugal or evaporation. So it also known as concentrated latex

Application Scope:
Dairy separator: skim milk or clarify milk (out of solid impurities). Small separation machine is hand-driven, artificial discharge, suitable for pastoral herdsmen's home use ; large separators for industrial production, electric drive, automatic or artifical discharge.
Mineral oil separator: for fuel oil, diesel oil, lubricating oil and transformers oil etc similar emulsion,remove mechanical impurities and water.
Vegetable oil separator: for vegetable oil refining.
Animal oil separator: for refining animal fat in meat processing, or for fish oil concentration and separation processing.
Yeast separator: for concentrated yeast, nozzle discharge.
Starch separator: for removing protein in the starch and concentrating starch, nozzle discharge.
Lanolin separator:in wool industry for extracting lanolin,nozzle discharge.
Pharmaceutical disc separator: for the extraction of antibiotics, vitamins in the pharmaceutical industry;also for separating liquid-solid three-phase mixture in the pharmaceutical and chemical industry.
Beer separator: for beer, malt juice and other beverages clarification.
Latex separator: for concentrating rubber latex and out of impurities.
Paint separator: for separating impurities in the coating, to improve the quality of the coating.
My company can individually design and manufactur different separator according to different material and Processes.

Application Occasion

Detailed imagesPackingCompany information

If you need further information, please contact us freely, we will do our best to cooperate with you.
